The Emerson FloBoss S600 is a highly advanced flow computer designed for precise measurements in hydrocarbon liquid and gas environments. It is particularly suited for applications requiring fiscal measurement, custody transfer, batch loading, and meter proving.（ FloBossS600 www.plc-module.com）
Click to preview the file, or download it：
FLOBOSS S600.pdf
Versatile Applications: Capable of handling multi-stream, multi-station setups, allowing for simultaneous metering of both liquids and gases.
Application industry:Wide Measurement Standards Support: Compatible with AGA, ISO, GPA, GERG, GOST for gas applications and API and ASTM for liquid applications.
Expandable Architecture: Comes standard with one P144 I/O board and one P148 Pulse Mezzanine, with options for additional expansion boards like the P154 Prover board, P188 HART board, and P190 2nd Ethernet board.
High Precision Calculations: Utilizes 64-bit (double) precision floating point numbers for all metering calculations, ensuring high accuracy.
Robust Connectivity: Offers multiple communication interfaces including Ethernet, HART, RS-232, RS-422/RS-485, and a dedicated configuration port for software integration.
Embedded Web Server: Allows for remote access and management of the device, enhancing operational efficiency and ease of maintenance.
Technical Specifications:
Input/Output Capability: Initially equipped with a single I/O board suitable for 2 out of 3 streams and a header, expandable up to 10 streams and 2 headers with additional I/O boards.
Supported Meter Types: Includes orifice, ultrasonic, turbine, positive displacement, Coriolis, Annubar, Venturi, and V-Cone flow meters.
Processing Power: Incorporates a hardware floating point processor in the main CPU, with each additional card having local processing capabilities.
Security and Auditability: Features an embedded web server with user name and password protection, detailed event logs, and supports Windows Internet Explorer version 5 or greater.
Considerations:
Complexity: The FloBoss S600 is designed for complex applications requiring high precision and versatility. Users should be prepared for the setup and maintenance complexities associated with such a sophisticated device.
The Emerson FloBoss S600 is a robust and versatile flow computer designed for demanding industrial applications. Its advanced features and expandable architecture make it a valuable asset for companies seeking to enhance the accuracy and reliability of their fluid measurement processes.
